Ideal for a gravel / travel bike build

SEIDO MGV Carbon Disc Fork

Used for two months to test a rigid fork on my gravel bike.

Steerer comes cut to 16cm, so will not fit bigger bikes or higher bar positions. Includes steerer expander and cap and 45deg crown race (removable).

Pickup in Zurich

NP 315 CHF

Specs:

STEERER Tapered, 1-1/8"" - 1-1/2"", 300 mm length
S.H.I.S. DIMENSIONS 28.6 | 40
OFFSET 53 mm
AXLE TO CROWN 410 mm
HUB SPACING 100 mm
BRAKE Flat Mount 160, rotor size 160 - 180 mm
INTERNAL ROUTING Brake hose / dynamo cable
MOUNTS Triple cage / head light / mudguards / lowrider rack
INCLUDED Through axle, expander, cable port plugs
WEIGHT 530 g (w/o through axle, w/o bolts, uncut steerer)
TIRE CLEARANCE 58 - 622 (29"" x 2.25"") / 64 - 584 (27.5"" x 2.5"")
MAXIMUM SYSTEM WEIGHT 140 kg
EXTRA INFO Ready for fully internal cable routing, lowrider compatible
FORK STEERER INNER DIAMETER 23.6 mm
CROWN DIAMETER 57 mm
ASTM RIDING CONDITION 2
HUB TYPE 12 x 100 mm
AXLE TOTAL LENGTH (CLOSED) 120 mm
AXLE DIAMETER 12 mm
AXLE THREADING DIAMETER X PITCH M12 x 1.5
MIN. THREAD LENGTH 14 mm
MAX. DIAMETER HUB ENDCAPS 19 mm
